Overview

Model #991159

Let’s be honest, not all lawns are worthy of a machine of this caliber: tons of power that delivers a meticulous cutting performance on a mower with a distinctive design. That’s the Ariens APEX. Different models are equipped with a Kawasaki FR V-Twin or a Kohler 7000 Series V-Twin. Either one will help you quickly transform any grass into a beautifully manicured lawn. And this machine looks as great as it mows, with phenomenal graphics and a new premium stitched high back seat.

• 23 HP, 726cc V-Twin Kawasaki FR series engine is a commercial grade power plant that features cast iron cylinder liners for long life, automatic compression release for easy starting and internally vented carburetor for better fuel management

• 52-Inch commercial grade 10-gauge welded deck design that's 5.5 inches in deep with a reinforced leading edge provides the airflow needed to tackle tough mowing conditions with an increased evenness of cut

• Commercial hydro-gear ZT 3100 trans axles provide enhanced torque and load capacity with mowing speeds of 8 mph forward and 4 mph reverse

• Self-adjusting belt tension technology keeps deck belt tension constant, which maximizes belt life, minimizes wear and maintains a consistent, quality cut with minimal adjustments necessary

• Easy and intuitive foot-operated deck lift system provide effortless adjustments between 15 cutting positions in 1/4-in increments from 1.5 inches to 5 inches with a simple vertical pin selection

• Commercially inspired design with automotive style welded steel frame rails and ROPS (roll over protection system) capable

• Backed by Ariens 4 year/500 hour limited warranty (whichever occurs first, see warranty download for full program details)

Specifications

Series Name: APEX

Type: Zero-turn riding lawn mower

Dimensions and Capacity

• Assembled Weight: 832 lbs

• Fuel Capacity: 5.1 gallons

• Cut Width: 52 inches

• Overall Length: 79 inches

• Overall Width with Deck: 67 inches

• Engine Oil Capacity: 64 oz

• Rear Wheel Size: 22 inches

• Front Wheel Size: 13 inches

Key Features

• Ammeter: No

• Hour Meter Type: Meter only

• Bagger Capable: Yes (Leaf bag not included)

• Blade Engagement (PTO): Electric

• Lowe’s Exclusive: Yes

• Commercial/Residential Use: Residential

• Maximum Forward Speed: 8 mph

• Cruise Control: No

• Maximum Reverse Speed: 4 mph

• Cup Holder: Yes

• Mulching Capable: Yes (kit sold separately)

• Deck Gauge (Thickness): 10 gauge (steel)

• Number of Blades: 3

• Deck Type: Fabricated steel

• Number of Deck Positions: 15

• Differential: Standard

• Number of Anti-Scalp Wheels: 6

• Discharge Location: Side

• Oil Filter Type: Standard

• Transmission Type: Dual hydrostatic

• Drive Type: Rear wheel drive

• Operator-Controlled Mow-in-Reverse: Yes

• Attachment Compatibility: Rear compatible

Engine and Performance

• Engine Brand: Kawasaki

• Power Source: Gasoline

• Engine Displacement: 726 cc

• Engine Horsepower: 23 HP

• Engine Series: Kawasaki FR691

• Engine Type: V-twin

• Start Type: Turn key start

• Steering Type: Dual lap bar

• Front Axle: Steel

• Maximum Cutting Height: 5 inches

• Minimum Cutting Height: 1.5 inches

• Grease Fittings: No

• Headlights: No

• Recommended Terrain: Flat with obstacles

Comfort and Safety

• Seat Type: High-back with lumbar support and armrests

• Engine Oil Included: Yes

Warranty

• Coverage: 4-year limited or 500 hours

Compliance and Certifications

• CA Residents Prop 65 Warning: Yes

• CARB Compliant: No

• Safety Listing: Not safety listed

Miscellaneous

• UNSPSC Code: 27112000
