John Deere Z950M ZTrak™ Zero-Turn Mower – Professional Power and Precision

The John Deere Z950M ZTrak™ Zero-Turn Mower is a premium commercial-grade machine designed for professional landscapers who demand exceptional performance, durability, and comfort. Engineered with productivity in mind, the Z950M is equipped with a powerful 27-horsepower FX850V Kawasaki engine, delivering reliable performance under the toughest mowing conditions.

Powerful Engine & Fuel Efficiency

• Engine: Kawasaki FX850V, 27 hp (20.1 kW) at 3,600 rpm

• Displacement: 852 cc, twin-cylinder, air-cooled

• Fuel Type: Gasoline, with propane fuel option available

• Fuel Capacity: 11.5 U.S. gallons (43.5 L)

• Fuel Consumption: 1.1–1.9 gal/hr (4.2–7.2 L/hr) depending on workload

Superior Mowing Deck Options

The Z950M features the 7-Iron™ PRO mowing deck, forged from 7-gauge steel for unmatched strength and longevity. Choose from several deck configurations:

• 54 in. (137 cm) 7Iron™ PRO Mulch On Demand™

• 60 in. (152 cm) 7Iron™ PRO side-discharge

• 72 in. (183 cm) 7Iron™ PRO side-discharge

• 72 in. (183 cm) FastBack™ PRO rear-discharge

Blade tip speed reaches up to 18,500 fpm, ensuring a clean, professional cut every time.

Smooth Hydrostatic Transmission & Mobility

• Transmission: Heavy-duty Tuff Torq hydrostatic with integrated piston wheel motors

• Travel Speed: Up to 12 mph (19.3 km/h) forward and 4.5 mph (7.2 km/h) reverse

• Drive Wheels: 24x12-12 with 4 PR load rating

• Caster Wheels: 13x6.5-6 flat-free tires

Reliable Drivetrain & PTO

• Hydraulic System: 5.9 qt (5.6 L) capacity with replaceable internal filter

• PTO Drive: Electro-magnetic clutch delivering 225 lb-ft (305 Nm) of torque

• Drive System: Durable V-belt mechanism

Operator-Focused Features

• Rollover Protection System (ROPS): Foldable for easy transport and storage

• Height of Cut: Adjustable from 1 to 5.5 in. (2.54 to 14 cm) in 0.25-in. increments

• Comfort: Ergonomic twin-lever control, standard digital hour meter, Brake-N-Go starting system

Durability & Dimensions

• Deck Construction: Reinforced 7-gauge (0.179 in./4.6 mm) steel deck

• Machine Length: 84 in. (213 cm)

• Width: Varies from 68 to 86 in. (173 to 218 cm) depending on deck

• Height: 73 in. (185 cm) with ROPS up, 47 in. (119 cm) with ROPS down

• Weight: 1,296–1,412 lb (588–640 kg)

Warranty & Protection

The Z950M is backed by a 36-month or 1,200-hour warranty (whichever comes first), with no hour limitation during the first 24 months. Designed for slope operation up to 20° (10° with material collection system).
